NetGain Micro 840 - 100V - 250A System

NetGain Micro 840 - 100V System - 24mm keyed Drive End Shaft. HyPer-Drive X125 Controller - 80/100V, 250A, Non-Isolated Logic. Includes Standard Ampseal Wire Harness and GV200QA-1 Contactor. Micro 840 stands out as a premium Internal Permanent Magnet (IPM) motor. This motor seamlessly pairs with any HyPer-DriveTM Inverter to form the Micro 8 SystemTM - an optimal power-train solution for light-weight vehicles or industrial equipment. Distinguished by its high compression potted stator, the Micro 840TM ensures unparalleled reliability and thermal transfer. The independent IP rating of IP65 can be increased to IP67 with an optional shaft seal, or to IP69k when mated to a sealed gearbox.

- Type: IPM
- Voltage: 48V Nominal
- Current: 250-750 Arms
- Peak Efficiency: 95%
- S2-5min Power: 25kW
- Continuous Power: 5.5kW
- Max Speed: 7,000RPM
- Torque Peak: 46 lbs.-ft. (450A)
- Motor Diameter: 8.19”
- Motor Length: 4.73”
- Motor Weight: 25 lbs.
- Shaft: 19mm Single Ended, Keyed
- Mounting: x4 M8 on 152mm BC
- Insulation: 2000C
- Software: SmartView
- Delivery: Stock
